OnChip's Micros G2 Tag offers our clients broader applications at an inexpensive cost.

With readability from a distance of 0-3mm, the applications for this unique design of RFID technology, becomes endless.

Asset Management & Supply Chain Inventory Reporting

OnChip's Micros G2 Tag has been embedded into semi-conductor components to facilitate inventory tracking in the manufacturing of integrated circuits. Micros G2 Tag's also confirm the authenticity of these products against their warranty and possible forgery attempts.

Medical Accuracy & Loss Prevention

OnChip's Micros G2 Tag can be embedded in metal, plastic, glass, and have been used in the medical settings to track inventory of prescription drugs.

Authenticity of Designer Products

OnChip's Micros G2 Tag has been embedded in designer watches to ensure authenticity and end piracy. In several instances, our Micros G2 Tag has been implmented into designer accessories to create an unseen level of verifiable authenticity.

Anti-theft and Authenticity of Rare Art

OnChip's Micros G2 Tag has also been used to tag expensive, one of a kind, priceless art. Micros G2 Tag can be attached to the most inconspicuous spot. Barely seen by the trained eye.

Tracking the movement and existance of Bee's

OnChip's Micros G2 Tag can also be used to tag Bee's to track their migration and movement within the hive. Studies are currently underway to assist researcher's explain the vast reduction in bee population.

All OnChip tags are compatible with RAIN:  http://rainrfid.org/about-rain/what-is-rain/

Genesis XL Tag Specifications:

101386- Genesis XL Tag (UHF)

Size: 0.41mm x 0.43mm x 0.09mm *

Support Protocol: OCA,  EPC Class 1 UCODEG2XMUHF ISO 18000-63

Operating Frequency: 840MHz-960MHz(UHF).

* Not yet available for MP.

Micros G2 Tag Specifications:

102779 - Micros G2 Tag (UHF)

Size: 0.41mm x 0.43mm x 0.125mm

Support Protocol: OCA,  EPC Class 1 UCODEG2XMUHF ISO 18000-63

Operating Frequency: 840MHz-960MHz(UHF).

102779 - Micros G2 Tag (UHF) is also available in an adhesive substrate for spraying onto a metal or solid surface, at 15~18psi.

Antenna's:

• 001-Micro Antenna (externalized). Dental (read range: contact).

• 003-Micro Spot Antenna (externalized). Near field (read range: 0mm to 3mm).

• 004-Micros Stripe Antenna (externalized) 2-3cm long. Near field (read range: 0mm to 3mm).

Reader's:

• Mobile Reader (general specifications): R/W EP Global UHF Class 1 Gen2 Reader for Android powered handsets and tablets. USB version. Additional information on purchasing will be supplied upon request.

• Stationary Reader: UHF RFID - Internet Ready
